Porting – Wireless Applications

Porting is the adaptation of a piece of software so that it will function in a different computing environment to that for which it was originally written.  It is the process where an Application migration involves moving an application built for one mobile platform to another.

Porting is making changes to software to make it run on different environment. Porting with respect to ‘wireless’ basically means to try and ‘fit’ one application into a variety of mobile devices from a variety of manufacturers and platforms. The ‘fitting’ includes two activities related to, but distinct, from porting called emulating and cross-compiling.

Porting is usually required because of differences in the central processing unit, operating system interfaces, different hardware, or because of subtle incompatibilities in or even complete absence of the programming language used on the target environment. It is far more cost effective to outsource the testing and porting of your mobile games & application to a third party.

In mobile game development, porting is the most important phase where the game has to run on a large number of models and has to cover most new models to get through the market.

Demand for mobile applications continues to increase day by day. This presents a huge opportunity as well as challenges for both small and large mobile development companies. One of biggest challenges facing the mobile application development companies is the sheer number of different operating systems,   devices, device features, screen sizes and market requirements. Porting applications (iPhone, iPad, Android, BlackBerry, Windows Mobile, Palm etc.) from one mobile device to another mobile device has become a critical challenge for every mobile development company.

In the past many mobile application development companies have considered applications porting in-house. However, just collecting the information and guidelines on this large number of mobile platforms and devices it-self could prove to be overwhelming and expensive. It is important to have a well-defined porting strategy in place to ensure smooth porting. Porting strategy addresses various mobile application-porting pitfalls that might arise.

Regular Expression

Regular Expressions describes or matches a set of strings. It is often called a pattern as it describes set of strings.

Given underneath is one of the most widely used and ever confused BackLash character. The remaining expressions are serialized below that.

Using the Backslash Character

A backslash (\) instructs QuickTest to treat the next character as a literal character, if it is otherwise a special character. The backslash (\) can also instruct QuickTest to recognize certain ordinary characters as special characters. For example, QuickTest recognizes \n as the special newline character.

For example:

w matches the character w

\w is a special character that matches any word character including underscore

For example, in QTP, while entering the URL of a website,


The period would be mistaken as an indication of a regular expression. To indicate that the period is not part of a regular expression, you would enter it as follows:

mercurytours\.mercuryinteractive\.com Note: If a backslash character is used before a character that has no special meaning, the backslash is ignored. For example, \z matches z.

Expressions & Explanation

Special characters and sequences are used in writing patterns for regular expressions. The following describes the characters and sequences that can be used.


Marks the next character as either a special character or a literal. For example, “n” matches the character “n”. “\n” matches a newline character. The sequence “\\” matches “\” and “\(” matches “(“.


Matches the beginning of input.


Matches the end of input.


Matches the preceding character zero or more times. For example, “zo*” matches either “z” or “zoo”.


Matches the preceding character one or more times. For example, “zo+” matches “zoo” but not “z”.


Matches the preceding character zero or one time. For example, “a?ve?” matches the “ve” in “never”.


Matches any single character except a newline character.


Matches pattern and remembers the match. The matched substring can be retrieved from the resulting Matches collection, using Item [0]…[n]. To match parentheses characters ( ), use “\(” or “\)”.


Matches either x or y. For example, “zwood” matches “z” or “wood”. “(zw)oo” matches “zoo” or “wood”.


n is a nonnegative integer. Matches exactly n times. For example, “o{2}” does not match the “o” in “Bob,” but matches the first two o’s in “foooood”.


n is a nonnegative integer. Matches at least n times. For example, “o{2,}” does not match the “o” in “Bob” and matches all the o’s in “foooood.” “o{1,}” is equivalent to “o+”. “o{0,}” is equivalent to “o*”.


m and n are nonnegative integers. Matches at least n and at most m times. For example, “o{1,3}” matches the first three o’s in “fooooood.” “o{0,1}” is equivalent to “o?”.


A character set. Matches any one of the enclosed characters. For example, “[abc]” matches the “a” in “plain”.


A negative character set. Matches any character not enclosed. For example, “[^abc]” matches the “p” in “plain”.


A range of characters. Matches any character in the specified range. For example, “[a-z]” matches any lowercase alphabetic character in the range “a” through “z”.


A negative range characters. Matches any character not in the specified range. For example, “[m-z]” matches any character not in the range “m” through “z”.


Matches a word boundary, that is, the position between a word and a space. For example, “er\b” matches the “er” in “never” but not the “er” in “verb”.


Matches a non-word boundary. “ea*r\B” matches the “ear” in “never early”.


Matches a digit character. Equivalent to [0-9].


Matches a non-digit character. Equivalent to [^0-9].


Matches a form-feed character.


Matches a newline character.


Matches a carriage return character.


Matches any white space including space, tab, form-feed, etc. Equivalent to “[ \f\n\r\t\v]”.


Matches any nonwhite space character. Equivalent to “[^ \f\n\r\t\v]”.


Matches a tab character.


Matches a vertical tab character.


Matches any word character including underscore. Equivalent to “[A-Za-z0-9_]”.


Matches any non-word character. Equivalent to “[^A-Za-z0-9_]”.


Matches num, where num is a positive integer. A reference back to remembered matches. For example, “(.)\1” matches two consecutive identical characters.


Matches n, where n is an octal escape value. Octal escape values must be 1, 2, or 3 digits long. For example, “\11” and “11” both match a tab character. “011” is the equivalent of “01” & “1”. Octal escape values must not exceed 256. If they do, only the first two digits comprise the expression. Allows ASCII codes to be used in regular expressions.


Matches n, where n is a hexadecimal escape value. Hexadecimal escape values must be exactly two digits long. For example, “\x41” matches “A”. “\x041” is equivalent to “\x04” & “1”. Allows ASCII codes to be used in regular expressions.

Working with Excel Objects in QTP

We create framework for automating the application. For this we need the independent structure for reporting and data. Excel plays a very important role in this approach.

QTP has its own test result displaying mechanism in the predefined format. Once the test is run, the result sheet is generated which gives you the insight of the script – stating the point of failures, warnings and passes.

We create customized checkpoint in the script and it is possible to customize the result file also depending upon the checkpoint created will be passed or failed.

In most of the cases we want to create summarized or detailed report of the entire test in excels. The reason to create customized report is that one is able to keep the file in central location and to create the report in our own format.

In this article we are going to learn the interaction of Excel with VBScript.

The whole mechanism goes in the following steps:

1. Understanding the hierarchy of Excel Application.

2. Creating the Excel Object

3. Opening an existing workbook or creating the new one

4. Setting the objects for various sheets in workbook.

5. Writing and fetching the data values in the cells.

6. Saving and closing the workbook

7. Closing the application and releasing the memory

We will go through each of the above stated steps with a suitable example to understand the approach properly.

Understanding the hierarchy of Excel Application

We will not go into the details of the complete hierarchy of the Excel application but to the extend what is required.

Excel Application




Creating the Excel Object

The first step towards the process of reporting via excel is to create object of Excel. Reporting in Excel can either be done in backend, without making the application visible or u can make it appear to user once the process of writing or fetching the data is going. In either way creating of the Excel Application object is required.

It goes as:

Dim xl

Set xl = CreateObject (“Excel. Application”)

Opening an existing workbook or creating the new one

Once the excel object has been created, it means that excel application has been invoked but is not visible. So either one can perform the operations like that or make the application visible and then perform the operations.

To make the application visible:

xl.visible = true

To open a new Workbook:


To open an existing Workbook:

xl.workbooks.Open(“File Name with complete path”)

Setting and accessing the objects of sheets in workbook.

Once the workbook has been opened, either existing or new one, we need to write some data in various cells in various sheets of that workbook.

By default there are 3 sheets in a workbook and various operations can be performed on. So one need create the object to reference these sheets as it becomes easy to access them and you don’t have to mention the complete hierarchy over and over again.

Say one has to create a reference for sheet with index i, which starts from 1

Set sht1 = xl.activeworkbook.sheets(1)

One can add or delete n number of sheets from the activeworkbook

To add a sheet in workbook –


To delete a particular sheet where i represent the index which starts from 1 –


To change the name of the sheets –

xl.activeworkbook.sheeets(1).name = “Name of your choice”

To count the total number of sheets in the workbook

Cnt = xl.activeworkbook.sheets.count

Writing and fetching the data values in the cells

To write the data in Excel sheet, one should know the cell address in which the data has to be written. Same thing goes for accessing the data from the cells

To write the data in sheet2 cell address as D8, we write the following command. Cell address here is represented by row number followed by column number –

xl.activeworkbook.sheets (2).cells (8, 4) = “hello”

To fetch the data from sheet3 cell address A7 –

Val = xl.activeworkbook.sheets (3).cells (7, 1)

If one has already created the object of the particular sheet, you don’t have to write the complete hierarchy but simply –

Object.cells (row, col) = value

Saving and closing the workbook

Once the work completed you can save the newly created workbook to a specified location or save the changes made to already existing opened workbook.

To save as in case of new workbook

xl.activeworkbook.saveas “path_with_file_name.xls”

To save in case of existing workbook


To close the workbook


Closing the application and releasing the memory

To close the application


To release the memory of all the objects

Set xl = nothing



Browser(“Google”).Page(“Google”).WebEdit(“q”).Set (a)

Browser(“Google”).Page(“Google”).WebButton(“Google Search”).Click

Dim xl

Set xl = CreateObject(“Excel.Application”)

xl.visible = true

‘To open a new Workbook:


‘To open an existing Workbook:


Set sht1 = xl.activeworkbook.sheets(1)

‘To change the name of the sheets

xl.activeworkbook.sheets(1).name = “kanak”

‘To count the total number of sheets in the workbook

Cnt = xl.activeworkbook.sheets.count

msgbox  Cnt

xl.activeworkbook.sheets(2).cells(8,4) = “hello”

xl.activeworkbook.sheets(4).cells(8,4) = “step command in QTP 9.2”

wait 3

Val = xl.activeworkbook.sheets(4).cells(8,4)

msgbox Val

wait 3

Browser(“Google”).Page(“Google”).WebEdit(“q”).Set (Val)

Browser(“Google”).Page(“Google”).WebButton(“Google Search”).Click

‘xl.activeworkbook.saveas “path_with_file_name.xls”




Software Quality Testing essentially validates that the final product meets the desired quality standard.

           Crowd testing is when a large group of people with diverse backgrounds try your product and then provide you with helpful feedback on usability, bugs and features. If your product depends on the diversity of the crowd it is important to know what the people in the crowd can or cannot do. These people are not buyers of your product, nor have intention of buying it in the future. Customers and potential buyers can be great testers, but hard to find issues are detected usually by Software Quality Analysts.

           Crowd testing is a broad but effective means of ensuring that all aspects are covered. Crowd testing can be used as an add-on prior to production release. This will be effective in catching any prevailing User Interface defects. The most important aspect of Crowd testing is to create a crowd that is composed out of a large group of diverse people. Crowd can be a group of test experts, domain experts, users and people from different background. A larger Crowd will add value. The product owner decides on the type of Crowd to be used for testing.

           Crowd testing can be used for testing mobile applications as well. This crowd consists of diverse and talented group of people. You can tap into the skills and knowledge of billions of people worldwide.

           Crowd testing is independent of the software development methodology. It can be used in both adaptive and predictive scenarios. Crowd testing can use the creativity and diversity of various testers around the world and not just a small user group to accept the software. It complements traditional testing. Normal test runs are still needed in previous test levels. Thus, organizations need to adapt a strategy that blends traditional and crowd testing approaches.

Usability Testing

Usability Testing is a technique for ensuring that the intended users of a system can carry out the intended tasks efficiently, effectively and satisfactorily.

In a usability test, representative users try to do typical tasks with the product, while observers, including the development staff, watch, listen, and take notes. The product can be a Web site, Web application, or any other product. It does not have to be a finished product. You should be testing prototypes from early paper-based stages through fully functional later stages.

Usability can be defined as the degree to which a given piece of software assists the to accomplish a task, as opposed to becoming an additional impediment to such accomplishment. The broad goal of usable systems is often assessed using several criteria:

· Ease of learning

· Retention of learning over time

· Speed of task completion

· Error rate

· Subjective user satisfaction

Usability is the combination of fitness for purpose, ease of use, and ease of learning that makes a product effective. Usability testing focuses on determining if the product is easy to learn, satisfying to use and contains the functionality that the users desire. The movement towards usability testing stimulated the evolution of Usability Labs. Many forms of usability testing have been tried from discount usability engineering, field tests to competitive usability testing. Apart from research and development of various testing methods there have been development in the field of automated tools for evaluation of interface designs against usability guidelines. Some of the tools are DRUM, WebCAT, WebSAT etc.

Goals of Usability Testing:

Usability testing is a black-box testing technique. The aim is to observe people using the product to discover errors and areas of improvement. Usability testing generally involves measuring how well test subjects respond in four areas: efficiency, accuracy, recall, and emotional response. The results of the first test can be treated as a baseline or control measurement; all subsequent tests can then be compared to the baseline to indicate improvement.

  • Performance — How much time, and how many steps, are required for people to complete basic tasks? (For example, find something to buy, create a new account, and order the item.)
  • Accuracy — How many mistakes did people make? (And were they fatal or recoverable with the right information?)
  • Recall — How much does the person remember afterwards or after periods of non-use?
  • Emotional response — How does the person feel about the tasks completed?

Hallway testing

Hallway testing or hallway usability testing is a specific methodology of software usability testing. Rather than using an in-house, trained group of testers, just five to six random people, indicative of a cross-section of end users, are brought in to test the software the name of the technique refers to the fact that the testers should be random people who pass by in the hallway. The theory, as adopted from Jakob Nielsen’s research, is that 95% of usability problems can be discovered using this technique.

Remote testing

Remote usability testing is also known as unmoderated or asynchronous usability testing which involves the use of a specially modified on line survey, allowing the quantification of user testing studies by providing the ability to generate large sample sizes. Additionally, this style of user testing also provides an opportunity to segment feedback by demographic, attitudinal and behavioral type. The tests are carried out in the user’s own environment helping further simulate real-life scenario testing. This approach also provides a vehicle to easily solicit feedback from users in remote areas.
